Upper and lower suspension arms
| # | Part | Part no. | Price | Stock | |
|---|---|---|---|---|---|
| 1 | Upper suspension arm | UAH 444 | 9 pcs | ||
| 2 | Arm ball joint assy | UAH 462 | 11 pcs | ||
| 2-1 | Hex nut M16*1.5*H7.5 | on order | on order | ||
| 2-2 | Stepped hex nut M14*1.5*H9 | on order | on order | ||
| 3 | Slotted nut M12*1.25 | UAH 22 | 15 pcs | ||
| 4 | Cotter pin 2.5*24 | UAH 0 | 5 pcs | ||
| 5 | Front arm rubber seal cap | UAH 31 | 2 pcs | ||
| 6 | Rocker arm plastic bushing | on order | on order | ||
| 7 | Steel bushing Φ10.2*16*H142 | UAH 72 | 19 pcs | ||
| 8 | Front arm steel bushing Φ10.2*16*H46 | UAH 31 | 66 pcs | ||
| 9 | Flange lock nut M10*1.25 | UAH 13 | 5 pcs | ||
| 10 | Left lower suspension arm | UAH 807 | 7 pcs | ||
| 11 | Flange bolt M10*70*1.25 | on order | on order | ||
| 12 | Flange axle Φ10*165 M10*1.25 | on order | on order | ||
| 13 | Right lower suspension arm | UAH 807 | 8 pcs | ||
| 14 | Lower arm ball joint assy | UAH 376 | 30 pcs | ||
| 15 | Upper suspension arms assy | on order | on order | ||
| 16 | Left lower arm assy | on order | on order | ||
| 17 | Right lower arm assy | on order | on order | ||
| 18 | Spring washer Φ16.5*24*3.5 | on order | on order |
Rear suspension swingarm assy
| # | Part | Part no. | Price | Stock | |
|---|---|---|---|---|---|
| 1 | Swingarm assy | on order | on order | ||
| 1 | Swingarm assy | UAH 2,456 | 2 pcs | ||
| 2 | Swingarm plastic bushing | on order | on order | ||
| 3 | Swingarm dust cap | UAH 67 | 6 pcs | ||
| 4 | Chain cover mounting plates | on order | on order | ||
| 5 | Swingarm lower guard | UAH 712 | 6 pcs | ||
| 6 | Swingarm inner bushing Φ14.5*20*L225 | UAH 125 | 3 pcs | ||
| 7 | Flange lock nut M14*1.5 | UAH 13 | 4 pcs | ||
| 8 | Flange lock nut M14*1.5 | UAH 13 | 4 pcs | ||
| 9 | Oil cooler rubber bushing | on order | on order | ||
| 10 | Oil cooler bushing | on order | on order | ||
| 11 | Chain cover | UAH 157 | 3 pcs | ||
| 12 | Chain 530H 76L | UAH 663 | 16 pcs | ||
| 12-1 | Chain joint | on order | on order | ||
| 13 | Flange axle Φ14*265 M14*1.5 | on order | on order | ||
| 14 | Hex socket head cap screw M8*65 | on order | on order | ||
| 15 | Flange bolt M6*12 | on order | on order | ||
| 16 | Swingarm mounting block | on order | on order | ||
| 17 | Swingarm lower mounting block | on order | on order | ||
| 18 | Swingarm assy (kit) | on order | on order | ||
| 19 | Chain guide sleeve Φ31.8*46.5*H35 | UAH 40 | 10 pcs | ||
| 20 | Swingarm stepped bushing Φ14.1*30*H9 | on order | on order |
